5” Blower SERIES
RPE make 5” Twin Lobe Roots Blowers series comprises of total 5 models i.e. RPE-53, RPE-55, RPE-57, RPE-59, RPE-512 having:
Capacity Range: 80 m3/hr to 700m3/hr
Pressure Range: Upto 0.7kg/cm²
Motor HP: 5 HP to 20HP
Applications Industries: STP/ETP, Aquaculture, Pneumatic Conveying etc.
Description
| RPE-53 AC
(65NB Inlet/Outlet) |
||||||||||||||
| PRESSURE | 1000mmWC | 2000mmWC | 3000mmWC | 4000mmWC | 5000mmWC | 6000mmWC | 7000mmWC | |||||||
| SPEED | Q
(m³/h) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/h) |
BHP | Q
(m³/h) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/hr) |
BHP |
| 900 | 122 | 0.85 | 107 | 1.42 | 96 | 2.00 | 86 | 2.56 | 78 | 3.14 | 70 | 3.71 | 63 | 4.28 |
| 1200 | 174 | 1.13 | 159 | 1.89 | 148 | 2.66 | 138 | 3.41 | 130 | 4.18 | 123 | 4.96 | 116 | 5.73 |
| 1500 | 226 | 1.41 | 212 | 2.37 | 201 | 3.33 | 191 | 4.28 | 183 | 5.24 | 175 | 6.19 | 168 | 7.15 |
| RPE-55 AC
(80NB Inlet/Outlet) |
||||||||||||
| PRESSURE | 1000mmWC | 2000mmWC | 3000mmWC | 4000mmWC | 5000mmWC | 6000mmWC | ||||||
| SPEED | Q
(m³/h) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/h) |
BHP | Q
(m³/h) |
BHP | Q
(m³/hr) |
BHP |
| 900 | 213 | 1.25 | 191 | 2.23 | 173 | 3.20 | 159 | 4.19 | 146 | 5.17 | 135 | 6.16 |
| 1200 | 303 | 1.67 | 281 | 2.98 | 263 | 4.28 | 248 | 5.58 | 235 | 6.90 | 224 | 8.20 |
| 1500 | 392 | 2.08 | 370 | 3.72 | 352 | 5.35 | 338 | 6.99 | 325 | 8.62 | 313 | 10.24 |
| RPE-57 AC
(80NB Inlet/Outlet) |
||||||||||
| PRESSURE | 1000mmWC | 2000mmWC | 3000mmWC | 4000mmWC | 5000mmWC | |||||
| SPEED | Q
(m³/h) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/h) |
BHP | Q
(m³/h) |
BHP |
| 900 | 300 | 1.61 | 271 | 2.95 | 250 | 4.30 | 231 | 5.62 | 215 | 6.96 |
| 1200 | 422 | 2.15 | 393 | 3.93 | 372 | 5.72 | 353 | 7.49 | 337 | 9.30 |
| 1500 | 544 | 2.69 | 515 | 4.91 | 494 | 7.15 | 475 | 9.37 | 460 | 11.61 |
| RPE-59 AC
(80NB Inlet/Outlet) |
||||||||||
| PRESSURE | 1000mmWC | 2000mmWC | 3000mmWC | 4000mmWC | 5000mmWC | |||||
| SPEED | Q
(m³/h) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/h) |
BHP | Q
(m³/h) |
BHP |
| 900 | 408 | 2.08 | 372 | 3.88 | 344 | 5.68 | 321 | 7.49 | 301 | 9.30 |
| 1200 | 572 | 2.77 | 536 | 5.17 | 509 | 7.58 | 486 | 9.99 | 465 | 12.38 |
| 1500 | 737 | 3.46 | 701 | 6.46 | 674 | 9.48 | 650 | 12.47 | ||
| RPE-512 AC
(100NB Inlet/Outlet) |
||||||||||
| PRESSURE | 1000mmWC | 2000mmWC | 3000mmWC | 4000mmWC | 5000mmWC | |||||
| SPEED | Q
(m³/h) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/hr) |
BHP | Q
(m³/h) |
BHP | Q
(m³/h) |
BHP |
| 900 | 521 | 2.57 | 477 | 4.86 | 443 | 7.16 | 413 | 9.44 | 388 | 11.74 |
| 1200 | 731 | 3.42 | 685 | 6.47 | 652 | 9.54 | 623 | 12.60 | 597 | 15.65 |
| 1500 | 940 | 4.28 | 895 | 8.10 | 862 | 11.93 | 832 | 15.74 | ||
